Description
Our Auger Torque package deal suitable for excavators from 1ton to 1.6ton. We are offering an all-in-one auger attachment solution for small excavators in the 1ton to 1.6ton range.
Included in our package deal:
- X1500 Earth Drill
- Double Pin Cradle Hitch – Fabricated to suit your excavator
- Tungsten Auger up to 300mm
- Pair of 1/2″ BSP Hydraulic Hoses – no couplers
All you require is a pair of hydraulic couplings to suit your machine
This package deal would be ideal for the following excavators (as a guideline):
JCB 8015
JCB 8018
Kubota KX014
Kubota KX016
Takeuchi TB016
Takeuchi TB216
Terex TC20
JCB 8008
Bobcat E10
Doosan DX10
Doosan DX16
Any excavator from 1t to 1.6t weight class
Earth Drill Specifications
X1500 Earth Drill
Mini excavators 1T to 2T.
Oil Pressure Range: 70 – 205 Bar
Torque Range: 511 – 1496 Nm
Oil Flow Range: 20 – 45 lpm
Speed Range: 44 – 98 rpm
Output Shaft: 65mm Round
Height: 585 mm
Width: 200 mm
Weight: 46 kg
Technical Specifications – PDF Download
X1500 Earth Drill Technical Specs
X1500 Earth Drill Speed Chart
X1500 Earth Drill Torque Chart
Auger Specifications
S4 Tungsten Auger
Overall length: 1.2m
Fully flighted: 950mm
Diameter: Up to 300mm
Hub Size: 65mm Round
Overall Length given includes wear parts.
All Auger Torque Augers are built from high grade steel and incorporate many features that will allow you to work more efficiently and will make your job easier. Shallow pitch flights ensure they will cut with maximum efficiency and heavy duty tubes, constant spiral cut as well Auger Torques unique Shock Lock™ Tooth Locking System.
Hitch Specifications
Double Pin Cradle Hitch
The Double Pin Cradle Earth Drill hitch is to suit standard and quick hitch solutions on most excavators & backhoes. The use of a Cradle hitch is recommended by Auger Torque as it will eliminate Auger swing during dirt shake off, will enable you to safely transport your Earth Drill and Auger on site and will also help you in lining up your holes with precision.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style hitch.
Please note all hitches are made to order and can sometimes carry a lead time of 3/4 days. Please contact us for exact lead time
